MainThe main tabernacle consisted of two oak cheek boards 11.5 cm (4.5 in) thick and 25 cm (10 in) wide, of a length to stand 1.07 metre (3 ft. 6 in) above the deck and reach down 1.52 metre (5 ft) to each side of the keelson, to which they are through bolted. The upper part of the boards are through-bolted to the forward (for’d) main cargo hatch beam. An oak cross piece, or cleat rail, is bolted on the fore edges of the cheeks 0.9 metre (3 ft.) above deck level with an iron mast band above it. Both cheeks are bored through their sides for a 5 cm (2 in) diameter steel pin upon which the mast pivots.
MizzenThe mizzen tabernacle is of similar construction, with 10 cm (4 in) thick cheeks which stand 0.9 metre (3 ft.) above the deck. The cheeks are bolted one each side of the keelson and to the forward (for’d) side of beam No.8, which also support the forward end of the deckhouse.
|Base bolted to the keelson.|
